Understanding and Setting DIMSCALE in CAD Software

The DIMSCALE system variable is a crucial element in AutoCAD and other Computer-Aided Design (CAD) programs, dictating the size of dimensioning elements such as text, leader arrowheads, and extension line offsets. Manipulating this variable allows users to ensure their dimensions are appropriately scaled for print output. To view or modify the current DIMSCALE value, simply type DIMSCALE into the command line of your CAD software.

Determining the Correct DIMSCALE Value

To ascertain the appropriate DIMSCALE for your drawing, you need to consider the relationship between a physical measurement on a printed page and the actual size it represents on the plan. Essentially, you’re answering the question: “If I printed this drawing on paper and measured one inch on the physical page, how many inches (or feet or meters) would that correspond to on the actual plan?”

The concept hinges on your drawing’s base unit. Architectural drawings often utilize smaller units like inches or centimeters, while site plans tend to employ larger units such as feet or meters.

Identifying Your Drawing’s Base Unit

If you’re uncertain about your drawing’s base unit, follow these steps:

1. Enter UNITS at the command line.
2. Note your current Length Type setting. Change it to Decimal and save the alteration.
3. Enter DIST at the command line and measure a known distance, like the width of a door or a parking space.
4. (Optional) If you altered the Length Type in step 2, run the UNITS command again to revert it to its original setting.

Use the distance measured in step 3 to determine your drawing’s base unit. For instance, using the approximate width of a door:

• An Inch base unit might be represented by 36 units.
• A Foot base unit could be 3 units.
• A Centimeter base unit might be 90 units.
• A Meter base unit could be 0.9 units.

Calculating Your Scale Factor

Once your base unit is identified, you need to convert your drawing’s scale factor to that unit. The value on the other side of the equation, once your base unit is on one side, will be your DIMSCALE.

Let’s assume your base unit is inches:

• For a 1/8″=1′ scale: Convert 1′ to 12″, resulting in 1/8″=12″. Multiply both sides by 8 to get 1″=96″. Therefore, use a DIMSCALE of 96.
• For a 1″=20′ site plan: Convert 20′ to inches, yielding 1″=240″. This gives a DIMSCALE of 240.
• For a 3/16″ = 1′ scale: Convert 1′ to 12″ to get 3/16″ = 12″. Multiply both sides by 16 to get 3″ = 192″. Finally, divide both sides by 3 to get 1″ = 64″, meaning a DIMSCALE of 64.

If your base unit is a foot, you can apply the same methodology: either convert the scale so that 1′ is on one side of the equation instead of 1″, or divide the final value by 12. Similarly, the common DIMSCALE values can be divided by 12 for drawings with a foot base unit. This same logic extends to metric base units. Proper DIMSCALE settings are essential for creating clear and accurate technical drawings.
